Test push/pull strength and functional task requirements up to 500 lbF (2,500 N)

These kits make job task analysis and ergonomics analysis simple and accurate, ideal for workplace design, strength assessment, and ergonomic studies. These kits present the ergonomist and other professionals with a simple and economical testing solution.

The kit includes a force gauge with data output, MESUR™ Lite data collection software, and a USB cable.

The kits are available in 100 lbF (500 N), 200 lbF (1,000 N), and 500 lbF (2,500 N) capacities.

	Data Sheet

• Digital force gauge Series 3
  - ±0.3% accuracy
  - USB output
  - Compact design, easy to hold
  - Measures in lbF, ozF, kgF, or N
  - Peak force capture for push and pull forces
  - Durable construction ensures longevity
  - Battery or AC operation
• MESUR™ Lite software
  Tabulates continuous or individual data points from the gauge. One-click export to Excel easily allows for further data manipulation.
• USB cable
  For data output to a PC
• Double- and single-handles
  Non-slip rubber handles for good grip and consistent test results.
• Padded attachments
  Flat, curved, and square padded attachments mount directly to the force gauge for conducting musculoskeletal strength analysis.
• Clevis grip
  Spring-loaded pin with ball plunger locks into place for added safety in pull tests.
• Flat attachment
  Round attachment for compression tests.
• Accessories
  Series EK3 kits include a cushioned carrying case, AC adapter, battery, user's manual, and NIST-traceable certificate of calibration.

All models include 110V AC adapters. Add suffix ‘E’ for euro plug (220V), ‘U’ for UK plug (220V), or 'A' for Australian plug (220V).
Ex: EK3-500E, EK3-200U, EK3-100A
